Nano Carbon Conductive Paste Carbon Concentration: 80–85% Base Solvent: n-Butyl Acetate
₹1475.00
🧪 Nano Carbon Conductive Paste
Carbon Concentration: 80–85%
Base Solvent: n-Butyl Acetate
⚙️ Technical Specifications
Property | Specification |
|---|---|
Material Name | Nano Carbon Conductive Paste |
Composition | Carbon nanoparticles in n-Butyl Acetate |
Carbon Content | 80–85 wt% |
Particle Size | 30–100 nm (typical) |
Appearance / Color | Black viscous paste |
Viscosity | 20,000–70,000 cP (typical, adjustable) |
Drying / Curing Temp | 100–200 °C (depending on substrate) |
Electrical Resistivity | 1–10 mΩ·cm (after curing) |
Solvent | n-Butyl Acetate |
Density | ~1.2–1.5 g/cm³ |
Storage Conditions | Store in sealed container at 15–25 °C, away from heat and direct sunlight |
🌟 Key Features
High-purity carbon nanoparticles (80–85%) for efficient conductivity
Uniform particle dispersion ensures smooth, defect-free coatings
Compatible with screen printing, stencil printing, and dispensing
Good adhesion to polymers, ceramics, metals, and flexible substrates
Solvent-based formulation allows controlled drying and easy processing
Suitable for low-cost, lightweight, and flexible electronics
🔬 Applications
Printed Electronics
Flexible circuits, sensors, and conductive tracks
EMI Shielding & Coatings
Lightweight conductive coatings for electronics
Energy & Storage Devices
Electrodes for supercapacitors, batteries, and fuel cells
Research & Development
Nanotechnology experiments, conductive composites, and coatings
⚠️ Handling & Storage
Store in a sealed container at 15–25 °C, away from heat, open flame, and direct sunlight
Use gloves, protective eyewear, and lab coat during handling
Avoid inhalation or skin contact; handle in a well-ventilated area
Stir gently before use to ensure uniform dispersion
